RATED POWER

8000VA/8000W

11000VA/11000W

PARALLEL CAPABILITY

YES, 6 units

INPUT

Voltage

230 VAC

Selectable Voltage Range

170-280 VAC (For Personal Computers) 90-280 VAC (For Home Appliances)

Frequency Range

50 Hz/60 Hz (Auto sensing)

OUTPUT

AC Voltage Regulation (Batt. Mode)

230VAC ± 5%

230VAC ± 5%

Surge Power

16000VA

22000VA

Efficiency (Peak)

93%

Transfer Time

10 ms (For Personal Computers), 20 ms   (For Home Appliances)

Waveform

Pure sine wave

Optional DC Voltage

12 VDC ± 5%, 100W

N/A

BATTERY

Battery Voltage

48 VDC

48 VDC

Floating Charge Voltage

54 VDC

54 VDC

Overcharge Protection

66 VDC

63 VDC

SOLAR CHARGER & AC CHARGER

Solar Charger Type

MPPT

Maximum PV Array Power

11000W (5500W x 2)

13000W (6500W x 2)

MPPT Range @ Operating Voltage

90 ~ 450 VDC

90 ~ 450 VDC

Maximum PV Array Open Circuit Voltage

500 VDC

500 VDC

Maximum PV Input Current

27A x 2(MAX 40A)

Maxmum Solar Charge Current

120A

150A

Maximum AC Charge Current

120A

150A

Maximum Charge Current

120A

150A

PHYSICAL

Dimension, D x W   x H (mm)

147.4 x 432.5   x 553.6

Net Weight (kgs)

18.4

Communication Interface

USB/RS232/RS485/WiFi/Dry-contact

OPERATING ENVIRONMENT

Humidity

5% to 95% Relative Humidity(Non-condensing)

Operating Temperature

-10°C to 50°C

Storage Temperature

-15°C to 60°C

STANDARD

Compliance Safety

CE

CE
