Rated power

1600VA/W

3200VA/W

4000VA/W

6000VA/W

Input

Voltage

230VAC

Selectable voltage range

170-280VAC(For personal computers); 90-280VAC(For home appliances)

Frequency range

50Hz/60Hz (Auto sensing)

Output

AC voltage regulation(Batt.mode)

230VAC±5%

Surge power

3200VA/W

6400VA/W

8000VA/W

12000VA/W

Efficiency (Peak)

93%

Transfer time

10ms(For personal computers); 20ms(For home appliances)

Waveform

Pure sine wave

Battery

Battery voltage

12VDC

24VDC

48VDC

Floating charge voltage

13.5VDC

27VDC

54VDC

Overcharge protection

16VDC

33VDC

63VDC

Solar charger & AC charger

Solar charger type

MPPT

Maximum PV array open

circuit voltage

500VDC

Maxlmum PV array power

2000W

3500W

5000W

7000W

MPPT range @operating voltage

30-450VDC

60-450VDC

Maximum solar charge current

80A

120A

Maximum AC charge current

60A

100A

Maximum charge current

80A

120A

General Parameters

Weight(kg)

5

5.5

8.5

9

Slze D * W * H(mm)

348*270*95

400*300*115

Degree of protection

IP20

Humidity

5% to 95% Relative humidity(Non-condensing)

Operating temperature

-10℃ to 50℃

Communication

Communication interface

Standard:RS232,USB; CAN&RS485; Optional: WiFi, Bluetooth

Safety standard

EN/EC62109-1,EN/EC62109-2
