Rated output power

12KW

15KW

Input(PV)

Max. Power

16KW

22.5KW

Nominal DC Voltage / Maximum DC Voltage

720Vdc/1000Vdc

MPPT voltage range(V)

350-950Vdc

Full MPP Voltage Range

400-850Vdc

400-850Vdc

Number of MPP Trackers / Maximum Input Current

2/A: 26A,B: 26A

2/A: 26A,B: 26A

AC output

Max. output current(A)

40

40

Grid voltage/range(V)

230 VAC (P-N)/400 VAC   (P-P)/176-270

Output Voltage Range

184-265 VAC* per phase

Frequency(Hz)

50 /60

PF

0.9lagging-0.9leading

EFFICIENCY

Maximum Conversion Efficiency (DC/AC)

>96%

European Efficiency@ Vnominal

>95%

BATTERY & CHARGER

Maximum Charging Power

12KW

15KW

Battery voltage range(V)

40~60 Vdc

Max. charge current(A)

250

300

Battery type

Lithium /Lead-acid

UPS output

Rated power

12KW

15KW

Rated output voltage(V)

230 VAC (P-N)/ 400 VAC (P-P)

Rated frequency(Hz)

50/60

Efficiency (DC to AC)

>93%

General Parameter

Degree of protection

IP65

Operation temperature

-25° C~ 60° C

Cooling

Natural

Relative humidity

0~100%(Non-condensing)

Altitude

0-1000m

Dimensions(W*D*H)(mm)

660*255*750

Net Weight(kg)

75

78

Display and communication

Display

LCD

Interface

RS-232,RS-485, USB, CAN and Wi-Fi

Safety standard

IEC 62116,IEC 62727,IEC   61683,IEC 62109,IEC 61000-6-2:2019,IEC 61000-6-4:2019.IEC 61000-3-11:2019.EN 61000-3-12:2011

Grid Connection Standard

NRS097-2-1:2017,VDE-AR-N4105，G99
