ELECTRICAL PARAMETERS AT STC

Rated Maximum Power (Pmax) [W]

595

600

605

Open Circuit Voltage (Voc) [V]

52.58

52.79

53

Maximum Power Voltage (Vmp) [V]

44.64

44.85

45.05

Short Circuit Current (Isc) [A]

13.99

14.04

14.09

Maximum Power Current(Imp) [A]

13.33

13.38

13.43

Module   Efficiency [%]

23

23.2

23.4

Power Tolerance

0-+3%

Temperature Coefficient of lsc

0.045%/°C

Temperature Coefficient of Voc

-0.250%/°C

Temperature Coefficient of Pmax

0.290%/°C

STC

Irradiance 1000w/m²,cell temperature 25°C,AM1.5G

MECHANICAL PARAMETERS

Cell

Mono

Weight

31.8kg

Dimensions

2278士2mmx1134士2mmx30士1 mm

Cable Cross Section Size

4mm²(IEC), 12 AWG(UL)

No. of cells

144(6x24)

Junction Box

IP68, 3diodes

Connector

QC 4.10-351/ MC4-EVO2A

Front Glass/Back Glass

2.0mm/2.0mm

Packaging Configuration

36pcs/Pallet,720pcs/40HQ Container

OPERATING CONDITIONS

Maximum System Voltage

1500VDC

Operating Temperature

-40°C~+85°C

Maximum Series Fuse Rating

30A

Maximum Static Load, Front

5400 Pa (112 lb/ft²)

Maximum Static Load, Back

2400 Pa (50 lb/ft²)

NOCT

45士2°C

Safety Class

Class ll

Fire Performance

UL Type 29/class C

Certificates

IEC 61215, IEC 61730, IEC 62941, IS0 9001, IS0 14001,

IS0 45001,UL 61215, UL 61730
