Rated Power

1500VA/1500W

3000VA/3000W

4200VA/4200W

6200VA/6200W

INPUT

Voltage

230 VAC

Selectable Voltage Range

170-280 VAC (For Personal   Computers) ; 90-280 VAC (For Home Appliances)

Frequency Range

50 Hz/60   Hz (Auto sensing)

OUTPUT

AC Voltage Regulation (Batt. Mode)

230VAC ± 5%

Output Power

1500W with PV & battery 1200W with battery only

3000W with PV & battery 2500W with battery only

4200W with PV & battery 4000W with battery only

6200W with PV & battery 5000W with battery only

AC Output No.

Single

Single

Dual Outputs

Dual Outputs

Surge Power

3000VA

6000VA

8400VA

12400VA

Efficiency (Peak)

93%

Transfer Time

10 ms   (For Personal Computers) ; 20   ms (For Home Appliances)

Waveform

Pure sine   wave

BATTERY

Battery Voltage

12 VDC

24 VDC

48 VDC

Floating Charge Voltage

13.5 VDC

27 VDC

54 VDC

Overcharge Protection

16 VDC

32 VDC

63 VDC

SOLAR CHARGER & AC CHARGER

Solar Charger Type

MPPT

Maximum PV Array Open Circuit Voltage

350 VDC

450 VDC

500 VDC

Maximum PV Array Power

2000W

3000W

5000W

6500W

Maximum PV Input Current

13 A

13 A

18 A

18 A

MPP Range @   Operating Voltage

30 ~ 300 VDC(Min.60VDC   without battery connected)

30 ~ 400 VDC(Min.60VDC   without battery connected)

30 ~ 450 VDC(Min.60VDC   without battery connected)

90 ~ 450 VDC(Min.100VDC   without battery connected)

Maximum Solar Charge Current

100 A

100 A

120 A

100 A

Maximum AC Charge Current

80A

80A

100A

100A

Maximum Charge Current

100A

100A

120A

100A

PHYSICAL

Dimension, D x W   x H (mm)

90 x   288 x 357

115 x 300 x 435

115 x 300 x 435

Net Weight (kgs)

6.6

7.1

9

10.4

Communication Interface

RS232/RS485(BMS)/WiFi

ENVIRONMENT

Humidity

5% to   95% Relative Humidity (Non-condensing)

Operating Temperature

-10°C to 50°C

Storage Temperature

-15°C to 60°C
